Self Loading Concrete Mixer

Output Capacity: 1.6m3 / 2.2m3 / 4m3
Speed: Low: 0-9km/h High:0-25km/h
Loader Control: Hydraulic 4 way stick

TAG:  Self Loading Concrete Mixer

E-mail:sales@unique-cons.com
  • Overview
  • Parameters
  • Configuration
  • Downloads
Self loading concrete mixer is combine concrete truck mixer with concrete mixer, self loading concrete mixer can automatic feeding, metering, and mixing to discharge, and more, it can realize the transportation and site construction operations, which greatly improves the work efficiency, reduce production cost and time.

UNIQUE Group-Stone Crusher|stone crusher plant|Concrete Mixing Plant|Concrete mixer pump|Jaw crusher|Impact crusher|Cone crusher|water drilling machine

TAG:  Self Loading Concrete Mixer

Parameters of Self loading Concrete Mixer:

1.6m3 / 2.2m3 / 4m3 concrete mixers for choose

Name

Item

Specification



1.6m3 self loading concrete mixer

Net

5500 KG

Transmission

Full Hydraulic

Brake

Air Brake

Chassis

Off-road

Loader bucket

capacity

0.4m3
Control

Hydraulic

Mini turning radius

4.5M/R



Engine

Rated Power/RPM

60KW/2200RPM

Max.Torque/RPM

360N.M/1400RPM

Cylinder

4

Starter

Electric

Cooling type

water cooling

Maxing Drum

Output capacity

1.6M3


Bank Angle

16 °

Chute

Swing Angle

≥50°


 Angle control

 Hydraulic

 Loader control

 Hydraulic 4 way stick

Over size

5400x2400x3500mm


Above is 1.6m3 concrete mixer, if interest in 2.2m3 and 4m3 concrete mixer , please contact us!




TAG:  Self Loading Concrete Mixer
Working processing of Self Loading Concrete Mixer:
1. by charging scoop,small amount of sand and gravel is loaded into the mixing drum,
2. self-loading concrete mixer interior injected into water, when the supply water flow is completed, adding cement, self-loading concrete mixer will run to the designated place to unload concrete, at the same time, the mixing drum will keep rotating to ensure that the concrete dose not condense.
3. mixing drum is equipped with the screw type of blade,, the maximum savings in working time and raw material,
4. After working, the completion of the need for equipment to be cleaned to ensure that the normal work in the future.
