MODEL: HBTS6013
Filling height: 1400mm
GROSS WEIGHT: 6300kg
Distrbution valve: S-tube
Hopper volime: 0.6m3
The theortical outlet pressure (low): 7.6Mpa
The theortical outlet pressure (high): 13Mpa
Maximum concrete output (low): 60m3/h
Maximum concrete output (high): 36
UNIQUE Group could manufacture all kinds of concrete pumps such as small models with capacity 20,25, 30,40m3/h, medium models with capacity 40, 50m3/h, large models with capacity 60, 803/h. All the models could be driven by electric motor or diesel engine.
It is widely used in pumping mortar, fine stone concrete, normal concrete, high performance concrete in small, medium and large construction projects such as building, tunnel, bridge, high way, hydropower, mining and national defense etc.
| MODEL | HBTS6013 | HBTS8013 | HBTS8016 |
| Filling height | 1400mm | 1400mm | 1400mm |
| GROSS WEIGHT | 6300kg | 6800kg | 7000kg |
| Distrbution valve | S-tube | S-tube | S-tube |
| Hopper volime | 0.6m3 | 0.6m3 | 0.6m3 |
| The theortical outlet pressure (low) | 7.6Mpa | 7.6Mpa | 9Mpa |
| The theortical outlet pressure (high) | 13Mpa | 13Mpa | 16Mpa |
| Maximum concrete output (low) | 60m3/h | 80m3/h | 80m3/h |
| Maximum concrete output (high) | 36m3/h | 47m3/h | 46m3/h |
| Differential cylinder spercification | 125/80*1650 | 125/80*1650 | 140/90*1650 |
| Concrete pumping cylinder specification | 200mm | 200mm | 200mm |
| Diesel engine Power | 130KW | 145KW | 176KW |
| Hydraulic oil circuit type | Open | Open | Open |
| Main oil pump brand | Kawasaki or Rexroth | Kawasaki or Rexroth | Kawasaki or Rexroth |
| Main pump output | 125mm | 125mm | 125mm |
| Hydraulic Oil Tank Capacity | 500L | 500L | 500L |
1 Compact structure, easily moved, highly movable and flexible
2 Intelligent power control system with PLC for safe, smooth and efficient operation
3 Plunger pump with constant power, ensuring the efficiency of main engine
4 Equipped with wire remote controller, easy to operate
5 High performance sealing of S pipe valve installed with floating wear resistant ring
6 High delivery pressure to meet demand of high building and long distance projects
7 Low cost maintenance, beautiful appearances
