Suitable to 25-400t/h asphalt mixing plant, no pollution, environment friendly: burning efficiency up to 95% or more, smoke black level is 0-1 Lingeman level.
RM rotary pulverized coal burner Features:
1. Adopt new structure, change the traditional burner mechanism, burning fully.
2. High flame temperature, energy saving.
3. Adopt special refractory bricksto extend the service life.
4. 24 hours continuous production, do not need to remove slag every day.
5. low cost of production, only 1/3 of the oil burner.
|
Model |
RM500 |
RM1000 |
RM1500 |
RM2000 |
RM3000 |
RM4000 |
|
Power |
31.25 kW |
41.25 kW |
73.75 kW |
80.25kW |
138.45 kW |
202.45 kW |
|
Rated Coal Consumption |
500 kg/h |
1000 kg/h |
1500 kg/h |
2000 kg/h |
3000 kg/h |
4000 kg/h |
|
Mixture Temperature |
130-180℃ |
130-180℃ |
130-180℃ |
130-180℃ |
130-180℃ |
130-180℃ |
|
Main Machine |
LTZ40 |
LTZ80 |
LTZ120 |
LTZ160 |
LTZ240 |
LTZ320 |
|
Pulverize coal Machine |
FMJ40 |
FMJ80 |
FMJ120 |
2*FMJ80 |
2*FMJ120 |
3*FMJ120 |
|
Burning Efficiency |
≥95% |
≥95% |
≥95% |
≥95% |
≥95% |
≥95% |
|
Matching Asphalt Plant Capacity |
25-40 t/h |
70-85 t/h |
100-125 t/h |
140-170 t/h |
200-250 t/h |
280-320 t/h |
